IP Smart Set-top Box

Based on the GK6323V100B chip solution, it integrates a quad-core 64-bit Cortex A55 processor and a quad-core high-performance 3D GPU. It adopts 2GB DDR4 (compatible with 1GB), 8GB EMMC configuration, supports 4KP60 decoding, and supports HDMI 2.0a 4K ultra-high-definition video output. It is equipped with a built-in WiFi module and the entire machine is powered by an external 12V/1A power adapter. It is a smart set-top box with a novel appearance and rich interfaces.

Download Manual

Core Features
Technical Specifications

Core Features

GK6323V100B Main Chip

It adopts the GK6323V100B main chip, with a configuration of 2GB DDR4 (compatible with 1GB) and 8GB EMMC.
2.4GHz/5GHz

Supports 2.4GHz/5GHz IEEE 802.11a/b/g/n/ac;
Rich Peripheral Interfaces

The peripheral interfaces are rich, featuring 2 USB ports and supporting the connection of external storage devices.
4K Resolution

Supports output with a maximum resolution of 4K P60

Technical Specifications

"Chip and Configuration"
Main chip solution	GK6323V100B, main frequency 2GHz
Operating system	Android 4.4
Standard configuration	Flash	8GB EMMC
RAM	2GB DDR4, 1GB is optional
Wifi client	Supports 2.4GHz/5GHz IEEE 802.11a/b/g/n/ac (optional)
Interface
DC input	One
HDMI interface	One (2.0a
A/V interface	One MINI interface
USB interface	Two USB2.0 ports
Network port	One,10/100M adaptive
IR	One
Power supply specifications
Input voltage	External power adapter 12V/1A
Power consumption	Operating power consumption	≤10W
Standby power consumption	0.5 W or less</t
